The CMX jacket is UV resistant designed to withstand sunlight, snow, and ice.
Perfect for above ground applications
Optimum Performance
Suitable for 1 and 5 Gigabit speed up to 328 feet and 10 Gigabit speed up to 165ft depending on the installation environment.
Bandwidth tested up to 550 MHz.
Unshielded twisted pairs - U/UTP
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt)4PPoE up to 100W.
Sequential footage markings every 2 feet improve efficiency and easily allow you to track how much cable is left on the EZ Pull Reel.
Internal spline adds strength, fights against kinks, and further separates pairs for a cleaner signal.
Compatibility Counts
Terminate with Cat6/6A Unshielded Pass ThroughRJ45 connectors compatible with 23AWG solid conductors with an insulated conductor diameter of 1.01mm and an overall cable jacket diameter of 6.30mm.
Pure Solid Bare Copper Conductors
Complies with UL, ANSI/TIA, and U.S. product safety standards.
Bare copper is superior conductor material for data transmission and PoE use.
The only industry and governmental approved type of conductor for use in Ethernet networks.
✓ CERTIFIED by trueCABLE
Our data cables have been tested with a Fluke DSX-8000 Versiv CableAnalyzer and are in compliance with ANSI/TIA 568.2-D standards, RoHS-3 compliant, and cETLus certified.
The CMX jacket is UV resistant designed to withstand sunlight, snow, and ice.
Perfect for above ground applications
Optimum Performance
Suitable for 1 and 5 Gigabit speed up to 328 feet and 10 Gigabit speed up to 165ft depending on the installation environment.
Bandwidth tested up to 550 MHz.
Unshielded twisted pairs - U/UTP
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt)4PPoE up to 100W.
Sequential footage markings every 2 feet improve efficiency and easily allow you to track how much cable is left on the EZ Pull Reel.
Internal spline adds strength, fights against kinks, and further separates pairs for a cleaner signal.
Compatibility Counts
Terminate with Cat6/6A Unshielded Pass ThroughRJ45 connectors compatible with 23AWG solid conductors with an insulated conductor diameter of 1.01mm and an overall cable jacket diameter of 6.30mm.
Pure Solid Bare Copper Conductors
Complies with UL, ANSI/TIA, and U.S. product safety standards.
Bare copper is superior conductor material for data transmission and PoE use.
The only industry and governmental approved type of conductor for use in Ethernet networks.
✓ CERTIFIED by trueCABLE
Our data cables have been tested with a Fluke DSX-8000 Versiv CableAnalyzer and are in compliance with ANSI/TIA 568.2-D standards, RoHS-3 compliant, and cETLus certified.
These in-depth blogs will cover everything you need to know about trueCABLE’s product: Cat6 Outdoor Ethernet Cable｜Unshielded. On
the off chance there is something you still can't find we also offer our expertise through our
customer support
Q:May seem like a silly question but does this cat6 cable have Ethernet ports on either end? Or is it simply just the cable?
Answers (1)
trueCABLE
03/06/2023
A:Great question! All of our bulk Ethernet cable is unterminated.
J
Jeff11/22/2022
Q:Does this cable have the jelly inside the jacket?
Answers (1)
Anonymous
11/22/2022
A:No, this cable is not gel-filled.
Here is a link to our gel-filled cable: https://www.truecable.com/products/cat6-gel-filled-direct-burial-unshielded?variant=39302524010563
M
Mike10/10/2022
Q:Does this cable have the ability to be ran underground within conduit? I see that it is not for direct burial use.
Answers (1)
Anonymous
10/10/2022
A:Great question! We do not recommend running this cable through an underground conduit since it is not direct burial rated.
