No more load bars means less waste and frustration! The ability to see the conductors come through the front of the plug allows you to verify the correct TIA 568A or 568B color sequence which minimizes bad terminations.
Maximum Performance
Ensuring the best cable to plug combination, pass through plugs allow a push-pull method to seat the cable jacket as far into the plug as possible.
Triple prong gold plated contacts.
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt)4PPoE up to 100W.
Versatile
Works with 23AWG stranded or solid conductors.
Suitable for cable jacket diameters up to ∅7.30mm and conductor insulation diameters from ∅0.95 - 1.05mm.
No more load bars means less waste and frustration! The ability to see the conductors come through the front of the plug allows you to verify the correct TIA 568A or 568B color sequence which minimizes bad terminations.
Maximum Performance
Ensuring the best cable to plug combination, pass through plugs allow a push-pull method to seat the cable jacket as far into the plug as possible.
Triple prong gold plated contacts.
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt)4PPoE up to 100W.
Versatile
Works with 23AWG stranded or solid conductors.
Suitable for cable jacket diameters up to ∅7.30mm and conductor insulation diameters from ∅0.95 - 1.05mm.
These in-depth blogs will cover everything you need to know about trueCABLE’s product: Cat6/6A Pass Through RJ45 Connectors｜Unshielded. On
the off chance there is something you still can't find we also offer our expertise through our
customer support
Our All-In-One Crimp and Termination Tool performs multiple functions simultaneously. Very little maintenance is required to keep your tool in top functioning condition. It will provide you many years of service.
I have used a lot of different RJ45 connectors over the years & these are top notch. Everything I have purchased from trueCABLE has been excellent quality. Also, they ship quickly which is much appreciated for those of us who are always running behind!
Q:I just bought a spool of cat 6 utp and RJ45 connectors. can't fit into connectors - conductors measure 1.06. shouldn't they be less than 1.02?
do you make oversize rj45?
Answers (1)
trueCABLE
03/28/2024
A:Hello! Based upon a 1.06mm insulated conductor diameter, we do make a larger pass-through connector called Cat6A XL Passthrough RJ45 Connector that will likely fit your cable. We also make a standard load bar version (Cat6/6A Standard Unshielded RJ45 Plug) that should work well too if you don't like passthrough connectors. Both types are very easy to use.
https://www.truecable.com/products/cat6a-xl-rj45-pass-through-connectors-unshielded
https://www.truecable.com/products/cat6-6a-standard-rj45-connectors-unshielded
G
george03/28/2024
Q:I just bought a spool of cat6 utp cmp, and matching pass through connectors. I can not insert the cable into the connector.
I measured the conductors and all were 1.3mm. isn't that WAY out of spec (i.e. 1.0 +- .02)?
so I have 1000 feet of unusable cable. now what? do you make a bigger RJ45?
Answers (1)
trueCABLE
04/15/2024
A:Hello George! Sorry, you are having trouble! If the conductors were 1.30mm, that would actually not even fit any keystone jack, much less an RJ45. That is large enough to be a 22AWG conductor. Do you mind checking the measurement of the conductors again? Even our largest RJ45 plug would not accept 1.30mm, nor would our tool-less keystone jacks designed for oversized insulation diameters. To further help we would need to see some pictures of your termination attempts. Please contact us at https://www.truecable.com/pages/contact-us so we can troubleshoot this with you directly. Thanks!
DH
Dennis H.10/23/2023
Q:Will these crimps do well with .50 insulation thickness?
Answers (1)
trueCABLE
10/24/2023
A:Hello! I am not sure if you are referring to mm or inches. I will assume mm. If your conductor insulation thickness is .50mm, then the conductor insulation diameter would be 1.00mm. These plugs would work for that. Be advised the plug will only accept up to 7.00mm cable jacket diameter, however.
C
Chris10/22/2023
Q:Will these work with 24 AWG Stranded ethernet cable?
Reference spec: (CAT.6a UTP, 24AWG (7/0.19mm AS)*4P, Stranded, OD:6.9mm, Jacket PVC)
Thank you!
Answers (1)
trueCABLE
10/23/2023
A:These connectors do accommodate both stranded and solid conductors, but they are only suitable for 23AWG.
M
Matt05/04/2023
Q:Are these connectors compatible with the klein pass through RJ45 crimpers?
Answers (1)
trueCABLE
05/04/2023
A:Yes, the Klein tool will work with the unshielded pass-through connectors.
