Cat6A Field Term Plug|Unshielded

Part Number - 6AFT_6pc

Features

  • Component Level Connector
  • Supports PoE++ (802.3bt) 4PPoE, up to 100W
  • Suitable for Unshielded Ethernet Cable
  • ANSI/TIA 568 2.D Certified

Need help finding compatible connectors for your Ethernet cable?

Look no further than our Connector Finder

Bulk Save with trueCABLE
Qty Price Per Item Your Savings
10-24 $30.22 2.5%
25-49 $29.44 5%
50+ $28.67 7.5%
$30.99 30.99
-Liquid error (sections/product-template line 309): Computation results in '-Infinity'%
Size
Quantity
Qty:
Add 9 more for 2.5% discount

Why buy direct from trueCABLE?

30 day returns

We stand by our products with our Forever Warranty

Same-day free shipping on orders placed Mon-Fri by 3pm Central.

Maximum Performance

  • ANSI/TIA 568-2.D Cat6A MPTL and Cat6A Patch Cord component level rated. Tested up to 600 MHz.
  • Suitable for 10 Gigabit (10/100/1000/10000 Mb/s) up to 328 feet.
  • Compatible with 23 to 24AWG solid copper conductors.
  • Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) 4PPoE up to 100W.
  • ETL verified to IEC 60512-99-002.
  • Press-Fit Technology makes our product more reliable and increases transmission performance.

Easy to Use

  • Self-terminating means no punch-down tool is required. Our 90-degree tool-less design provides maximum snap-shut confidence.
  • The termination holder cap is marked with highly visible colors for easy T568A or T568B wiring and helps keep conductor pairs separate.
  • Supports ∅6.00 - 8.50mm cable jackets and ∅0.86 - 1.20mm insulated conductors.

Versatile & Durable

  • 100% compatible with any RJ45 8P8C female Ethernet port. Three-way strain relief design allows you to bend the terminated cable to adapt to limited space providing installation flexibility. Compact enough to allow for high-density 48 port blade applications.
  • Compatible with U/UTP (fully unshielded) Ethernet cables. Our trueCLOSE tool is strongly recommended for effortless and accurate termination cap closure.
  • Fully backward compatible with Cat5e and Cat6 assuming the cable jacket outer diameter and insulated conductor dimension requirements stated above are obeyed.

Quality Guaranteed

  • ANSI/TIA 568 2.D Certified by trueCABLE. CE Listed. TUV RoHS-2 Certified, US TAA compliant, ISO/IEC Certified. Tested in the real world by real installers.

What's In The Box?

  • Each field termination plug includes a conductor holder, nylon tie, and full instructions. These durable and time-saving component-level field termination plugs are sure to make your installation hassle-free.
Weight 0.1 lbs
Length 4.50 in
Width 1.88 in
Height 1.25 in
Barcode X002YZQXPB

Maximum Performance

  • ANSI/TIA 568-2.D Cat6A MPTL and Cat6A Patch Cord component level rated. Tested up to 600 MHz.
  • Suitable for 10 Gigabit (10/100/1000/10000 Mb/s) up to 328 feet.
  • Compatible with 23 to 24AWG solid copper conductors.
  • Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) 4PPoE up to 100W.
  • ETL verified to IEC 60512-99-002.
  • Press-Fit Technology makes our product more reliable and increases transmission performance.

Easy to Use

  • Self-terminating means no punch-down tool is required. Our 90-degree tool-less design provides maximum snap-shut confidence.
  • The termination holder cap is marked with highly visible colors for easy T568A or T568B wiring and helps keep conductor pairs separate.
  • Supports ∅6.00 - 8.50mm cable jackets and ∅0.86 - 1.20mm insulated conductors.

Versatile & Durable

  • 100% compatible with any RJ45 8P8C female Ethernet port. Three-way strain relief design allows you to bend the terminated cable to adapt to limited space providing installation flexibility. Compact enough to allow for high-density 48 port blade applications.
  • Compatible with U/UTP (fully unshielded) Ethernet cables. Our trueCLOSE tool is strongly recommended for effortless and accurate termination cap closure.
  • Fully backward compatible with Cat5e and Cat6 assuming the cable jacket outer diameter and insulated conductor dimension requirements stated above are obeyed.

Quality Guaranteed

  • ANSI/TIA 568 2.D Certified by trueCABLE. CE Listed. TUV RoHS-2 Certified, US TAA compliant, ISO/IEC Certified. Tested in the real world by real installers.

What's In The Box?

  • Each field termination plug includes a conductor holder, nylon tie, and full instructions. These durable and time-saving component-level field termination plugs are sure to make your installation hassle-free.
